AM4331 Automatic glue dispenser machine

  • Model: AM4331
  • Brand: Aituo
  • Delivery: 15-20 working days
  • Warranty: 1 year

INQUIRY NOW

×Enter your message

1.The automatic hot melt gluing machine can be operated stand-alone without an external computer,easy to install and operate.

2.Programming with a hand-held programmer, achieved precise positioning and dispensing control for three-axis linkage, and realized the interpolation for spatial linear or two-axis circular. At the same time, the automatic dispensing machine has a CAD import function,which can be directly imported from the computer to draw the glue path, allowing you to complete the setting of any gluing path.

3.The automatic gluing machine has a trapezoidal and S-shape curve acceleration and deceleration function. It can prevent the sharp bend part from being stacked glue and accumulated glue, which can make the glue area more perfect.

4.Dispensing and sports mode online teaching function: it is easy to complete super-functions such as matrix copying, offset modification, and correction point setting for various paths...and program transfer between each machine.

5.The automatic gluing machine has separate universal input and output contacts.

6.It can store multiple independent running programs,which can be called quickly and easily when used again,without reprogramming.

7.Simple programming method,ready to use, it can be used without professional training,learning operation and maintenance are quick and easy.

8.This automatic hot melt gluing machine can also be customized according to different application requirements.

Number of control axis



Four axis



Effective stroke

X axis

400mm

500mm

600mm

Y1 axis

300mm

300mm

300mm

Y2 axis

300mm

300mm

300mm

Z axis

100mm

100mm

100mm



Dimension

W

580mm

580mm

580mm

D

620mm

720mm

820mm

H

590mm

590mm

590mm

Maximum speed

300mm/s(Can be customized up to 800mm/s)

Repeat accuracy

±0.02mm-0.05mm(Can be customized within±0.02mm)

Control system

Cooperate with domestic listed companies to develop teaching hand-held control system

Drive mode

Step/servo motor(imported from Japan),synchronous belt/Screw mandrel,Linear slide-way(Taiwan brand)

Program storage

It can store 1,000 sets of processing data,and a single processing file can occupy up to 3M storage space(5,000 processing points)

File storage space

Hand-held box 256M,card remover 32M,and a single processing file can occupy up to 3M storage space(100,000 processing points)

Support document

CAD、CORELDRAW

Maximum load

Y axis/Z axis 5KG/2KG

Power supply

AC220V/110V, 50-60HZ, 350W

Various solvents, adhesives,paints,chemical materials, solid glue, etc., including silica gel, EMI conductive glue,UV glue,AB glue, quick-drying glue,epoxy glue,polyurethane glue,sealant,hot glue,grease,silver glue,red glue,solder paste,thermal grease,solder paste,transparent paint,screw fixing agent,wood glue, anaerobic glue,acrylic glue,anti-wear glue,crystal glue,pouring glue,horn glue,instant glue,rubber,paint,enamel paint,lacquer,ink,pigment,etc.Which need to be heated.

It is mainly used for glue and other liquids in the product process to precise bonding, filling, sealing, dripping, linear/arc-shaped/circular of coating to the exact precise position of each product.
