AM204 Automatic twin wire cutting stripping and crimping machine

  • Model:AM204
  • Brand: Aituo
  • Delivery:15-20 working days
  • Warranty:1 year

INQUIRY NOW

×Enter your message





    Automatic wire cutting stripping and crimping machine adopts procedural control interface with touch screen LCD display, it has operate system in Chinese and English, easy to operate and stable performance. Fast send wire ,cut wire,strip wire and crimp the terminals,high precision, fast speed,front and rear swing arms are both controlled by servo,and ultra low noise,more stable. The length of sending/cutting/stripping wire,and the delay time of crimping,which all can be accomplished by digital configuration.

    Available wire size

    AWG16-AWG28#

    Cutting length

    45-3200mm( Longer can be customized)

    Cutting accuracy

    cutting length *0.2%

    Stripping length

    0.5mm-14mm

    Pressure capacity

    1.5T

    Detection device

    no wire;no terminal,insufficient pressure

    Voltage

    AC220V/50HZ single phase

    Air pressure

    0.5Mpa

    Dimension

    750mm*800mm*1700mm

    Weight

    400kg
