Model

AM207

Dimension

1250x750x1350

Weight

420KG

Function

cut wire; single/both end strip wire; sing end half strip,single end tin, tin several times

Control system

32bit computer system

Output

6000-8000pcs/h

Wire Range

AWG32-AWG18

Cutting Length

10-400mm(8mm available)

Cutting Torrance

0.2±0.02*L

Stripping Length

0-7mm

Twisting length

3-7mm

Tinning Length

0.5-7mm

Air pressure

5-6KG

Power Supply

AV220V 50HZ
