AM6096 Full automatic coaxial cable wire-stripping machine

  • Model:
  • Brand: Aituo
  • Delivery:
  • Warranty:

INQUIRY NOW

×Enter your message

Description

  1. Suitable for precision processing for various types of soft thin coaxial cable in communications and RF industry ;
  2. Advanced Rotary cutter with V-shaped cutting tool to make the machining process precise and highly efficient!
  3. With all complete function of wire cutting, multi-section stripping, mid-stripping, stripping with leaving glue, long and short stripping distance.
  4. Up to 100 groups of storage capacity make all kinds of processing data completely preserved, can transfer at any time!
  5. The silicone rubber high temperature cable, high elastic cable, precision medical cable and high-end car wires all can be processed perfectly on the machine without any hurt conductor!

Specification

  • Model: AM6096
  • Display: Touch screen
  • Interface: Chinese LCD 153*85MM
  • Suitable cable: Coaxial cable
  • Stripping length setting unit: 0.01mm
  • Cutting diameter range: 0.8-4.0mm
  • Cutting length setting unit: 0.01mm
  • Stripping length: right 120mm, left max45mm
  • Wight: 100KG
  • Drive mode:servo motor/ ball screw drive
  • Stripping way: rotary blade + cutting stripping blade
  • Maximum peeling layers: 6 layers
  • Voltage: AC220V/110V 50/60HZ
  • Weight: 100kg
  • Power: 800W
  • Dimension: 650*660*400mm
  • Blade: Imported tungsten steel + imported high speed steel
  • Work environment:-5---45 degrees, dry and vibration-free work surface
  • Memory function: can store max 100 program
  • Productivity: 750-1300pcs/h (depending on cable)
